1200L/1600L/2000L BLOW MOULDING MACHINE 2018-11-22T06:48:29+00:00


This series machine can help you to make big product like the IBC tank, water tank, plastic pallet, outside door, hospital bed and so on. This machine is with accumulator type in the die head, 100 point parison controller, bottom blowing device and take-out device. We can adjust the configuration in the machines according to all your requirement in the new project.

Technical Features:
1, Electronic control system: Japanese Mitsubishi PLC computer plus man-machine interface (Chinese or English) red paper, touch-screen operation. All process settings, changes, search, monitoring, fault diagnosis and other functions are achieved on the touch screen, no contact with the working principle, components and durable.
2, Hydraulic system: proportional pressure control, equipped with imported brand-name hydraulic components, stable and reliable.
3, Plasticizing system: efficient plasticizing mixing screw, plastic plastic to ensure adequate and uniform.
4, Speed control system: frequency control + alloy steel gear reducer, smooth speed, low noise, durable
5, Opening and closing mode, mobile system: beam arm, three o’clock, the center of the mold clamping mode, to ensure long-term use. Clamping force balance, no deformation, and the use of translation mode body (ball linear guide), high precision, less resistance, faster.
6, Blowing needle holder: the overall angle-type blowing needle holder, stable and not shift, to ensure that products cut smooth
Max.Product Volume(L)1200L1600L2000L
Dry cycle(pc/h)303030
Screw Diameter(mm)120×2120×2120×2
Screw L/D ratio(L/D)323232
Screw drive power(KW)132×2132×2132×2
Screw heating power(KW)23.6×223.6×223.6×2
No.of heating zone(Screw)(ZONE)6×26×26×2
Output of HDPE(kg/h)350×2350×2350×2
Hydraulic pump driving power(KW)11+15=2611+15=2611+15=26
Clamping force(KN)200020003000
Platen distance(mm)400~2800400~2000400~2000
Max.Size of Mold(W×H)(mm)1600×18001600×18001600×2000
Capacity of Accumulator head(L)6570100
Max.Die diameter(mm)7501400×1201500×120
Die heating power(KW)909095
No.of heating zone(ZONE)242430
Blowing pressure(Mpa)
Air consumption(M³/MIN)555
Cooling water pressure(Mpa)
Water consumption(L/MIN)350350350
Size of machine(L×W×H)(m)11.5×9×6.911.5×9×6.911.5×9×7.2
Weight of machine(TON)70~7570~7570~75
